Hydrogen storage tank winding machine
Our company independently researches, designs, and manufactures fully automatic dry winding machines for Type III and Type IV hydrogen cylinders for new energy vehicles.
Gantry-type three-position, dual-drive main frame
Carbon fiber and glass fiber winding systems
Servo tension control system
Servo Electronic Yarn Frame
Thermostatic Impregnation System
5-axis feeding trolley
Automatic yarn cutting, threading, inflation, and pressure stabilization system
Automatic labeling and weighing
Process
3-Φ650mm
Maximum effective winding diameter (mm)
3000mm
Maximum effective winding length (mm)
Axes 1-5
Winding station
Gantry-type three-position dual-drive main frame
Carbon fiber and glass fiber winding systems
Servo tension control system, servo electronic yarn frame
Thermostatic Impregnation System
5-axis feeding trolley
5-axis feeding trolley
Automatic yarn cutting, threading, inflation, and pressure stabilization system
Automatic labeling and weighing
